STV/Thirard/Mottura Project/DELTA WB4&GB5/Amig 10000&10000E (France/Poland/Spain/Italy)

Locksmith Impression Pick for cylinder locks STV/Thirard/Mottura Project/DELTA WB4&GB5/Amig 10000&10000E

It is recommended to use ready-made stick foil with a thickness of 0.06 mm in one or two layers.

Text in the 1st video: I'll show you the profile right away. The profile is essentially almost the same. These are Mottura Project, Amig, Delta. In general, a universal tool. Italian STV, Spanish Amig, there are two models. Polish Delta, there are also two models. Italian Mottura Project. It's all the same tool. And there are several more profiles, I just don't have them, with which it will also fit. Here, the opening rate is almost 90%, very high. And it fits the Thirard French lock. With such a profile, it fits here too. The only thing is that these Thirard, the opening rate is low. There are mushroom-shaped pins, they are very good, so the opening rate for them is low. For all the others, closer to 100%. The main foil is 0.6, regular cut. I will not open everything, now we will open a few. Just so as not to take up much time. Here is the reverse side, we make a form. And then we will put it on the working part. You can use thicker foil. But, as a rule, it is the usual cut 0.6. Sometimes, if, say, it did not work, you can simply put it in two layers. It is better to work up and down carefully, we make a stretch to the left. Stretch to the left and swing up and down. You can also do it a little this way. Amig Spanish lock. This is Polish Delta. There are two similar models. And so on. For example, if you work with Thirard, here, as I said, the probability of opening is very small. Let's try to open it. The mushrooms are good here. They just crunch when you open them. You can, of course, try different foils there, in different ways, but the percentage will still be low. This one opened right away, but it jams. This could be. Let's try. Let's try another one. We basically swing the same way. We pull to the left and swing up and down. Well, here I have pressed down the high pins already. Well, that's it. It's not easy with these locks. In general, the profile is universal. So, STV, Amig, Delta, Mottura Project, French Thirard are suitable. There are several more, there are just no locks in stock. Such a universal profile.

Text in the 2nd video: This is Mottura Project, this is Delta. There are two such Deltas similar. Amig, also two models of Amig. If they are under the Door Lock Cover, then it is very easy to confuse them, since they look the same. That is, it is difficult to understand whether this is a Project, Delta or Amig? In appearance, they are all almost the same if there is a Door Lock Cover on them. But this, in principle, does not matter, since the tool for all these cylinders is the same. Foil 05 is mainly used with everyone, and for Project you can use 06. Models Amig 10000 and 10000E, these are two models. Delta GB5 and WB4. Mottura Project. These 5 types of cylinders are opened by the same tool. And it opens well. Well, it quickly jammed, but here it is enough to put foil 06 and it will be better. Foil 06 is more stable. In general, regarding stable operation, it is much better not to lay the foil immediately on the working part, but first to lay it on the edge and thus make a shape. In this way, the shape is given, it then holds the heights well and thus a more stable work is obtained. Now let's try the Mottura Project. So I advise you to pre-make the form, and then transfer it to the working part. And insert carefully. Now Delta. Both Deltas open great. So, I lay it on the edge, shape it and transfer it to the working part. So, two Amig series, two Delta series (I just don't have a second cylinder now) and Mottura Project. It's all open with one tool. And it works great. The price of the tool will be on the site, the link is under this video.
