TESA TX80 TOPOLINO DECODER (Spain)

THE KIT INCLUDES

Topolino decoder for Tesa TX80

Spare pins - 8 pins

Reset cap for Tesa TX80

Reset hex key with code lines for code measuring

Plastic Transportation Box

Important: this tool if not to be used on different cylinder lock, only Tesa TX80. Not suitable for T80 model.

Since this Topolino decoder has a design meant for the cylinder lock Tesa TX80 Assa abloy, its structure is build accordingly. The pick consists of blade with 6 main pins and 2 side pins with a specific structure (please watch the video). Those pins are arranged in a certain order that corresponds to the lock it is made for. The tool is tightened with bolts, do not tighten them or manipulate them in any way! This will destroy the opening capabilities of the tool

PREPARATION AND RESET OF THE PINS

Insert the blade of the Topolino into the Reset Cap , the two arrows must match their position (watch the video). Slide back the Slider. Reset with the Reset reset hex key ALL 6 pins (push them all the way in). Reset the two additional pins with the small mouse reset tool! Slide to the front the slider. The decoder is ready to be used.
